Class 2 Carriage
Pallet Fork models AWPF8 and AWPF25 both feature a class 2 fork carriage, this is a standard forklift style carriage that offers greater support for loads of higher weights.
Class 1 Carriage
Models AWPF05, AWPF1 & AWPF5 all feature a Class 1 solid bar carriage. This carriage is suitable for the lower weight ranges and also offers a ‘floating fork’ feature as tines are only fixed at one point from which they can swing.
Full Range of Options
There are a full range of options for Rata Pallet Forks to make this attachment even more versatile. Side shifters and fork extensions can help to make your tractor as useful as any yard forklift!
Specifications
| Model (Code) | Description | Approx. Weight (kg) |
| AWPF05 | Adjustable width 500kg capacity | 90 |
| AWPF1 | Adjustable width 1000kg capacity | 125 |
| AWPF5 | Adjustable width 1500kg capacity | 163 |
| AWPF8 | Adjustable width 1800kg capacity | 171 |
| AWPF25 | Adjustable width 2500kg capacity | 235 |
| AWPF25T | Adjustable width 2500kg capacity (To suit telehandlers) | 250 |
| Other Pallet Fork options available on request
Weights are approximate only, and will vary depending on the hitch type |
||
Specifications (Fixed width models)
| Model (Code) | Description | Approx. Weight (kg) |
| ESPF1 | Economy fixed width 1,000kg capacity (Low back frame) | 78 |
| FWPF1 | Fixed width 1,000kg capacity | 102 |
| FWPF5 | Fixed width 1,500kg capacity | 155 |
| Note: 800mm outside of fork blades unless specified otherwise
Weights are approximate only, and will vary depending on the hitch type |
||
Specifications (Pallet Fork Options)
| Model (Code) | Description |
| HYDSS | Hydraulic side shift for AWPF8 & AWPF25 |
| HYDSS1 | Hydraulic side shift for AWPF5 |
| HYDSS2 | Hydraulic side shift for AWPF05 & AWPF1 |
| PF150 | Fork extension kit 150mm wide x 1800mm long |
| Note: HYDSS can be retrofitted. HYDSS1 & HYDSS2 have to be fitted at time of order. | |
